Technical Data

Rated Cross Section

Overall Diameter Of Cable

Current Carrying Capacity

Operating Inductance

Operating Capacity

Conductor DC Resistance at (20 oC)

Net Weight

Delivery Length

mm2

mm

Air (A)

Ground (A)

mH / Km

µF/km

Ohm / Km

Kg / Km

Mt

1x25/16

18.00

162

166

0.68

0.25

0.727

620

1000

1x35/16

19.50

196

198

0.66

0.28

0.524

710

1000

1x50/16

20.50

235

234

0.63

0.32

0.387

850

1000

1x70/16

22.00

293

286

0.60

0.37

0.268

1060

1000

1x95/16

24.00

358

341

0.58

0.41

0.193

1320

1000

1x120/16

25.00

413

387

0.56

0.46

0.153

1570

1000

1x150/25

26.50

469

431

0.54

0.50

0.124

1930

1000

1x185/25

28.50

537

485

0.53

0.54

0.0991

2290

1000

1x240/25

31.00

633

559

0.51

0.59

0.0754

2850

1000

1x300/25

34.00

722

626

0.49

0.60

0.0601

3470

1000

1x400/35

37.50

826

696

0.47

0.64

0.0470

4440

1000

1x500/35

41.50

943

777

0.46

0.67

0.0366

5490

1000

1x630/35

46.00

1069

860

0.44

0.74

0.0283

6860

1000
