Technical Data

Rated Cross Section

Overall Diameter Of Cable

Current Carrying Capacity

Operating Inductance

Operating Capacity

Conductor DC Resistance at (20 oC)

Net Weight

Delivery Length

mm2

mm

Air (A)

Ground (A)

mH / Km

µF / km

Ohm / Km

Kg / Km

Mt

1x35/16

40.00

177

165

0,73

0,12

0,524

2840

1000

1x50/16

41.00

253

232

0,71

0,13

0,387

3070

1000

1x70/16

43.00

312

282

0,68

0,14

0,268

3400

1000

1x95/16

46.00

373

332

0,64

0,15

0,193

4200

1000

1x120/16

47.50

425

373

0,62

0,17

0,153

4580

1000

1x150/25

49.00

476

410

0,60

0,18

0,214

5040

1000

1x185/25

51.00

536

456

0,58

0,19

0,0991

5600

1000

1x240/25

53.50

613

517

0,56

0,21

0,0754

6320

500

1x300/25

56.50

687

569

0,54

0,23

0,0601

7170

500

1x400/35

60.00

770

621

0,51

0,25

0,0470

8410

500

1x500/35

63.50

859

678

0,50

0,27

0,0366

9710

500

1x630/35

68.50

947

732

0,49

0,30

0,0283

11490

500
