Technical Data

Rated Cross Section

Overall Diameter Of Cable

Current Carrying Capacity

Operating Inductance

Operating Capacity

Conductor DC Resistance at (20 oC)

Net Weight

Delivery Length

mm2

mm

Air (A)

Ground (A)

mH / Km

µF / km

Ohm / Km

Kg / Km

Mt

1x35/16

33.00

158

157

0.69

0.12

0.868

1060

1000

1x50/16

34.00

218

196

0.66

0.13

0.641

1150

1000

1x70/16

36.00

272

237

0.63

0.14

0.443

1290

1000

1x95/16

37.50

330

282

0.60

0.15

0.320

1450

1000

1x120/16

39.00

381

321

0.59

0.17

0.2530

1570

1000

1x150/25

40.50

429

354

0.57

0.18

0.2060

1820

1000

1x185/25

42.50

490

400

0.55

0.19

0.1640

2000

1000

1x240/25

45.00

577

461

0.53

0.21

0.1250

2260

1000

1x300/25

47.50

656

516

0.51

0.23

0.1000

2500

1000

1x400/35

50.50

746

571

0.49

0.25

0.0788

2920

1000

1x500/35

54.00

835

634

0.48

0.27

0.0605

3400

1000

1x630/35

58.50

951

724

0.46

0.30

0.0469

3970

1000
