Technical Data

Rated Cross Section

Overall Diameter Of Cable

Current Carrying Capacity

Operating Inductance

Operating Capacity

Conductor DC Resistance at (20 oC)

Net Weight

Delivery Length

mm2

mm

Air (A)

Ground (A)

mH / Km

µF / km

Ohm / Km

Kg / Km

Mt

1x35/16

40.00

177

165

0,73

0,12

0,524

2000

1000

1x50/16

41.00

253

232

0,71

0,13

0,387

2210

1000

1x70/16

43.00

312

282

0,68

0,14

0,268

2490

1000

1x95/16

46.00

373

332

0,64

0,15

0,193

3000

1000

1x120/16

47.50

425

373

0,62

0,17

0,153

3340

1000

1x150/25

49.00

476

410

0,60

0,18

0,214

3750

1000

1x185/25

51.50

536

456

0,58

0,19

0,0991

4250

1000

1x240/25

53.50

618

517

0,56

0,21

0,0754

4900

500

1x300/25

56.50

687

569

0,54

0,23

0,0601

5650

500

1x400/35

60.00

770

621

0,51

0,25

0,0470

6790

500

1x500/35

63.50

859

678

0,50

0,27

0,0366

7980

500

1x630/35

68.50

947

732

0,49

0,30

0,0283

9610

500
