Technical Data

Rated Cross Section

Overall Diameter Of Cable

Current Carrying Capacity

Operating Inductance

Operating Capacity

Conductor DC Resistance at (20 oC)

Net Weight

Delivery Length

mm2

mm

Air (A)

Ground (A)

mH / Km

µF / km

Ohm / Km

Kg / Km

Mt

1x35/16

35.50

157

134

0.69

0.11

0.868

1040

1000

1x50/16

36.50

189

195

0.66

0.12

0.641

1110

1000

1x70/16

38.00

270

237

0.63

0.13

0.443

1240

1000

1x95/16

40.00

328

282

0.61

0.14

0.320

1375

1000

1x120/16

41.00

378

320

0.59

0.15

0.253

1495

1000

1x150/25

43.00

425

353

0.58

0.16

0.206

1715

1000

1x185/25

44.50

485

396

0.57

0.18

0.1640

1875

1000

1x240/25

47.00

573

457

0.55

0.19

0.1250

2125

1000

1x300/25

49.00

652

511

0.54

0.21

0.1000

2330

1000

1x400/35

52.00

740

566

0.53

0.23

0.0778

2725

500

1x500/35

54.50

838

630

0.51

0.25

0.0605

3160

500

1x630/35

59.00

953

719

0.50

0.29

0.0469

3675

500
