Technical Data

Rated Cross Section

Overall Diameter Of Cable

Current Carrying Capacity

Operating Inductance

Operating Capacity

Conductor DC Resistance at (20 oC)

Net Weight

Delivery Length

mm2

mm

Air

Ground

mH / Km

µF / km

Ohm / Km

Kg / Km

Mt

3x50/16

95.30

215

214

0,468

0,098

0,3870

15230

200

3x70/16

98.90

267

264

0,442

0,108

0,2680

16600

200

3x95/16

103.40

325

315

0,418

0,119

0,1930

18390

200

3x120/16

107.20

375

360

0,403

0,128

0,1530

20000

200

3x150/25

110.50

424

403

0,390

0,137

0,1240

21680

200

3x185/25

114.70

486

455

0,375

0,148

0,0991

23730

200

3x240/25

120.30

453

529

0,360

0,162

0,0754

26710

200

3x300/25

125.90

651

593

0,346

0,176

0,0601

29850

200
