Technical Data

Rated Cross Section

Overall Diameter Of Cable

Current Carrying Capacity

Operating Inductance

Operating Capacity

Conductor DC Resistance at (20 oC)

Net Weight

Delivery Length

mm2

mm

Air (A)

Ground (A)

mH / Km

µF / km

Ohm / Km

Kg / Km

Mt

1x25/16

22.00

167

165

0.69

0.16

0.727

730

1000

1x35/16

23.50

202

197

0.67

0.18

0.524

850

1000

1x50/16

24.50

241

233

0.64

0.20

0.387

1000

1000

1x70/16

26.00

300

285

0.61

0.23

0.268

1210

1000

1x95/16

28.00

365

340

0.59

0.26

0.193

1500

1000

1x120/16

29.50

421

386

0.57

0.28

0.153

1750

1000

1x150/25

31.00

477

431

0.55

0.30

0.124

2130

1000

1x185/25

33.00

545

485

0.53

0.33

0.0991

2500

1000

1x240/25

35.00

641

559

0.51

0.36

0.0754

3060

1000

1x300/25

38.00

728

626

0.50

0.40

0.0601

3680

1000

1x400/35

41.00

830

597

0.48

0.45

0.0470

4650

1000

1x500/35

44.00

950

780

0.46

0.49

0.0366

5680

1000

1x630/35

49.00

1078

865

0.46

0.54

0.0283

7050

1000
