Technical Data

Rated Cross Section

Overall Diameter Of Cable

Current Carrying Capacity

Operating Inductance

Operating Capacity

Conductor DC Resistance at (20 oC)

Net Weight

Delivery Length

mm2

mm

Air (A)

Ground (A)

mH / Km

µF / km

Ohm / Km

Kg / Km

Mt

3x50/16

86.50

214

214

0,45

0,11

0,387

13210

250

3x70/16

90.50

269

261

0,42

0,12

0,268

14610

250

3x95/16

94.50

326

313

0,41

0,14

0,193

16220

250

3x120/16

98.50

377

356

0,39

0,15

0,153

17770

250

3x150/25

101.00

426

400

0,37

0,16

0,124

19230

200

3x185/25

106.00

510

441

0,36

0,17

0,0991

21460

200

3x240/25

111.00

579

510

0,34

0,18

0,0754

24230

200

3x300/25

117.00

654

604

0,32

0,23

0,0601

27380

200
