Technical Data

Rated Cross Section

Overall Diameter Of Cable

Current Carrying Capacity

Operating Inductance

Operating Capacity

Conductor DC Resistance at (20 oC)

Net Weight

Delivery Length

mm2

mm

Air (A)

Ground (A)

mH / Km

µF / km

Ohm / Km

Kg / Km

Mt

3x50/16

82.00

166

168

0.45

0.11

0.641

9420

250

3x70/16

85.50

205

205

0.42

0.12

0.443

10320

250

3x95/16

90.00

249

246

0.41

0.14

0.320

11370

250

3x120/16

93.50

285

278

0.39

0.15

0.253

12250

200

3x150/25

96.50

322

311

0.37

0.16

0.206

13300

200

3x185/25

101.50

369

352

0.36

0.17

0.1640

14490

200

3x240/25

106.50

434

408

0.34

0.18

0.1250

16170

200

3x300/25

112.50

494

458

0.32

0.23

0.1000

17760

200

3x400/35

119.50

569

517

0.30

0.25

0.0788

19870

200
