Technical Data

Rated Cross Section

Overall Diameter Of Cable

Current Carrying Capacity

Operating Inductance

Operating Capacity

Conductor DC Resistance at (20 oC)

Net Weight

Delivery Length

mm2

mm

Air (A)

Ground (A)

mH / Km

µF / km

Ohm / Km

Kg / Km

Mt

1x25/16

20.00

164

166

0.69

0.20

0.727

660

1000

1x35/16

21.00

199

198

0.66

0.22

0.524

770

1000

1x50/16

22.00

238

233

0.64

0.25

0.387

910

1000

1x70/16

24.00

297

285

0.61

0.29

0.268

1130

1000

1x95/16

25.00

362

340

0.58

0.32

0.193

1400

1000

1x120/16

27.00

417

387

0.56

0.35

0.153

1640

1000

1x150/25

28.00

473

431

0.55

0.38

0.124

2020

1000

1x185/25

30.00

541

485

0.53

0.42

0.0991

2380

1000

1x240/25

33.00

637

559

0.51

0.46

0.0754

2930

1000

1x300/25

35.00

724

625

0.49

0.51

0.0601

3530

1000

1x400/35

39.00

824

696

0.47

0.57

0.0470

4500

1000

1x500/35

39.90

944

778

0.46

0.63

0.0366

5520

1000

1x630/35

43.70

1071

861

0.44

0.70

0.0283

6890

1000
