Technical Data

Rated Cross Section

Overall Diameter Of Cable

Current Carrying Capacity

Operating Inductance

Operating Capacity

Conductor DC Resistance at (20 oC)

Net Weight

Delivery Length

mm2

mm

Air (A)

Ground (A)

mH / Km

µF / km

Ohm / Km

Kg / Km

Mt

3x25/16

47.50

143

148

0.39

0.17

0.727

4040

500

3x35/16

50.50

173

178

0.37

0.19

0.524

4620

500

3x50/16

53.50

206

210

0.36

0.21

0.387

5320

500

3x70/16

57.50

257

256

0.34

0.24

0.268

6400

500

3x95/16

62.00

313

307

0.32

0.26

0.193

7620

500

3x120/16

65.50

360

349

0.31

0.29

0.153

8760

500

3x150/25

68.50

410

392

0.30

0.31

0.124

9970

500

3x185/25

72.50

469

443

0.29

0.34

0.0991

11560

250

3x240/25

81.50

553

513

0.28

0.39

0.0754

14500

250

3x300/25

84.50

635

579

0.27

0.42

0.0601

16660

250

3x400/35

91.50

731

650

0.26

0.48

0.0470

20260

250
