Technical Data

Rated Cross Section

Overall Diameter Of Cable

Current Carrying Capacity

Operating Inductance

Operating Capacity

Conductor DC Resistance at (20 oC)

Net Weight

Delivery Length

mm2

mm

Air 30 oC (A)

Ground 20 oC (A)

mH / Km

µF / km

Ohm / Km

Kg / Km

Mt

1x70/16

41,60

347

304

0,478

0,108

0,2680

1970

1000

1x95/16

43,40

420

360

0,453

0,119

0,1930

2280

1000

1x120/16

44,80

483

408

0,436

0,128

0,1530

2570

1000

1x150/25

46,20

540

445

0,422

0,137

0,1240

2970

1000

1x185/25

48,00

614

498

0,406

0,148

0,0991

3360

1000

1x240/25

50,30

718

569

0,389

0,162

0,0754

3970

1000

1x300/25

52,60

813

633

0,374

0,176

0,0601

4600

500

1x400/35

55,70

904

686

0,358

0,195

0,0470

5630

500
