Technical Data

Rated Cross Section

Overall Diameter Of Cable

Current Carrying Capacity

Operating Inductance

Operating Capacity

Conductor DC Resistance at (20 oC)

Net Weight

Delivery Length

mm2

mm

Air (A)

Ground (A)

mH / Km

µF / km

Ohm / Km

Kg / Km

Mt

1x35/16

30.00

169

165

0,694

0,12

0,524

1160

1000

1x50/16

32.00

248

232

0,668

0,14

0,387

1330

1000

1x70/16

33.50

307

284

0,637

0,15

0,268

1570

1000

1x95/16

35.50

373

339

0,612

0,17

0,193

1870

1000

1x120/16

37.00

439

385

0,593

0,18

0,153

2160

1000

1x150/25

38.50

484

430

0,578

0,19

0,124

2550

1000

1x185/25

40.50

552

484

0,561

0,21

0,0991

2950

1000

1x240/25

42.50

649

559

0,541

0,23

0,0754

3520

1000

1x300/25

45.50

737

627

0,524

0,25

0,0601

4170

1000

1x400/35

48.50

841

701

0,503

0,28

0,0470

5180

1000

1x500/35

51.20

963

786

0,487

0,30

0,0366

6250

500

1x630/35

56.50

1094

875

0,47

0,33

0,0283

7700

500
