Dimensions and Weights

Electrical Information

 Nominal
Cross section

Number Of
Wire/wire Dia

Overall
diameter approx

Net weight
approx.

Conductor DC (maks.)
resistance at 20 °C (maks.)

Calculated Min.
Break Strength

mm²

 Wire diameter

mm

kg/km

ohm/km

kN.

10 rm

7/1.32

3,96

85,8

1,915

3,96

16 rm

7/1.70

5,10

142,4

1,154

6,50

25 rm

7/2.12

6,36

221,4

0,742

9,99

35 rm

7/2.50

7,50

308,0

0,534

13,91

50 rm

7/3.00

9,00

443,5

0,369

19,57

50 rm

19/1.80

9,00

436,3

0,384

19,36

70 rm

19/2.12

10,60

605,2

0,275

26,55

95 rm

19/2.50

12,50

841,7

0,198

36,93

120 rm

19/2.80

14,00

1056,0

0,158

45,27

150 rm

37/2.24

15,68

1320,0

0,127

57,73

185 rm

37/2.50

17,50

1644,0

0,102

71,91

240 rm

61/2.24

20,20

2179,0

0,077

95,17

300 rm

61/2.50

22,55

2715,0

0,062

118,56
