Technical Data

Rated Cross Section

Overall Diameter Of Cable

Current Carrying Capacity

Operating Inductance

Operating Capacity

Conductor DC Resistance at (20 oC)

Net Weight

Delivery Length

mm2

mm

Air (A)

Ground (A)

mH / Km

µF/km

Ohm / Km

Kg / Km

Mt

3x25/16

42.50

141

149

0.37

0.20

0.727

3470

1000

3x35/16

46.00

171

176

0.35

0.22

0.524

4110

1000

3x50/16

49.50

196

208

0.34

0.25

0.387

4760

1000

3x70/16

53.00

249

255

0.32

0.28

0.268

5780

500

3x95/16

57.00

307

307

0.30

0.32

0.193

6910

500

3x120/16

61.00

353

353

0.29

0.35

0.153

8090

500

3x150/25

63.50

406

396

0.28

0.38

0.124

9270

500

3x185/25

68.50

464

447

0.27

0.42

0.0991

10860

500

3x240/25

77.00

548

523

0.26

0.47

0.0754

13610

250

3x300/25

82.00

632

581

0.26

0.48

0.0601

16130

250

3x400/35

90.00

726

653

0.25

0.52

0.0470

19920

250
