Technical Data

Rated Cross Section

Overall Diameter Of Cable

Current Carrying Capacity

Operating Inductance

Operating Capacity

Conductor DC Resistance at (20 oC)

Net Weight

Delivery Length

mm2

mm

Air (A)

Ground (A)

mH / Km

µF / km

Ohm / Km

Kg / Km

Mt

3x25/16

53.00

143

148

0.42

0.15

0.727

4770

500

3x35/16

55.50

173

178

0.40

0.16

0.524

5320

500

3x50/16

59.00

206

210

0.38

0.17

0.387

6130

500

3x70/16

63.00

257

256

0.36

0.19

0.268

7180

500

3x95/16

67.00

313

307

0.34

0.22

0.193

8420

500

3x120/16

71.00

360

349

0.33

0.24

0.153

9630

250

3x150/25

73.50

410

392

0.32

0.26

0.124

10830

250

3x185/25

79.00

469

443

0.30

0.28

0.0991

12800

250

3x240/25

86.50

553

513

0.29

0.31

0.0754

15500

250

3x300/25

90.00

635

576

0.28

0.34

0.0601

17750

250

3x400/35

97.00

731

650

0.27

0.38

0.0470

21420

250
