Technical Data

Rated Cross Section

Overall Diameter Of Cable

Current Carrying Capacity

Operating Inductance

Operating Capacity

Conductor DC Resistance at (20 oC)

Net Weight

Delivery Length

mm2

mm

Air (A)

Ground (A)

mH / Km

µF / km

Ohm / Km

Kg / Km

Mt

1x35/16

35.00

169

165

0,69

0,12

0,524

1260

1000

1x50/16

36.50

249

232

0,66

0,13

0,387

1420

1000

1x70/16

38.00

30

284

0,63

0,14

0,268

1665

1000

1x95/16

40.00

375

339

0,60

0,15

0,193

1955

1000

1x120/16

41.00

430

385

0,59

0,17

0,153

2230

1000

1x150/25

43.00

485

430

0,57

0,18

0,124

2610

1000

1x185/25

44.50

554

484

0,55

0,19

0,0991

3000

1000

1x240/25

46.50

653

559

0,53

0,21

0,0754

3575

1000

1x300/25

49.00

739

627

0,51

0,23

0,0601

4200

1000

1x400/35

52.00

842

701

0,49

0,25

0,0470

5200

500

1x500/35

55.00

965

786

0,48

0,27

0,0366

6245

500

1x600/35

60.00

1096

875

0,46

0,30

0,0283

7630

500
